As a professional foreign trade company specializing in metal forming equipment, we are committed to providing global customers with high-quality, cost-effective hat-shaped keel forming machines. Our equipment integrates advanced cold-forming technology, intelligent control systems and durable structural design, which is widely used in building partition walls, suspended ceilings, fire protection projects and other fields, helping customers reduce production costs, improve production efficiency and gain core competitiveness in the fierce market competition.

Hat-shaped keel forming machine is a specialized cold-forming equipment designed to continuously shape metal coils into precise and consistent hat-shaped keel profiles. Different from traditional labor-intensive processing methods such as cutting, bending and welding, our machine realizes automatic and continuous production, which not only ensures the uniformity of product quality, but also greatly improves production efficiency, making it an essential core equipment for modern metal processing, construction and decoration enterprises.

Core Advantages: Why Choose Our Hat-shaped Keel Forming Machine?

私たちは、グローバルな顧客の実用的なニーズに焦点を当て、生産と加工のペインポイントを解決するために、設備のそれぞれの利点を設計し、顧客に真の価値を創造しています。.

高精度と安定した品質

The forming rollers of the machine are made of high-quality GCR15 steel or CR12 steel, which are processed by high-frequency quenching and precision grinding, and the hardness reaches HRC 58-62 °, ensuring long-term stable operation and high precision forming. With multi-pass roller continuous forming technology and servo positioning system, the dimensional accuracy of the finished hat-shaped keel can reach ±0.15mm, the straightness error is less than 0.2mm/m, and the surface of the product is smooth, burr-free and free of scratches, with uniform thickness and consistent hat-shaped structure, which perfectly meets the assembly requirements of building partition walls, suspended ceilings, fire protection isolation and other scenarios. Whether it is standard or customized specifications, it can achieve consistent and high-precision forming, and the product qualification rate is as high as 99.8%.

完全自動化と高効率

The machine is equipped with a PLC + touch screen control system, which supports multi-language operation interfaces (English, Spanish, Arabic, French, etc.), and is simple and easy to operate, even new operators can get started quickly. It integrates uncoiling, leveling, punching, forming, hydraulic cutting and finished product collection into one continuous production line, realizing full automatic operation from raw material input to finished product output. The forming speed can reach 18-42 m/min, and the hydraulic cutting system can realize fast, clean and burr-free cutting without stopping the machine, which greatly improves production efficiency and reduces labor costs by 70% compared with traditional manual processing. At the same time, the machine can store 60+ sets of program parameters, which is convenient for quick switching between different specifications and models, and adapts to diversified and customized production needs.

省エネ・省資源・コスト削減

Adopting advanced cold-forming technology, the whole production process does not need heating, which avoids energy consumption caused by heat treatment and is more energy-saving and environmentally friendly. The metal material only undergoes bending deformation during the forming process, and the thickness basically remains unchanged, which significantly reduces raw material waste; at the same time, the precise cutting design and tailing recycling device minimize the tailing waste, and the material utilization rate is as high as 98.5% or more, effectively reducing the production cost of customers. In addition, the optimized frequency conversion power system of the machine further reduces energy consumption by 18-25% compared with ordinary models, and long-term use can save a lot of energy costs for customers.

強力な適応性と幅広い応用

Our hat-shaped keel forming machine has strong compatibility, which can process various materials such as mild steel, galvanized steel, aluminum and stainless steel, with a material thickness range of 0.4-5.0mm. It can be customized according to customer needs to produce hat-shaped keels of different widths (40-220mm) and heights (30-110mm), meeting the diverse needs of different construction projects. It is widely used in building partition walls (residential and commercial), suspended ceilings, fire protection projects (fire isolation keels), office buildings, shopping malls, hotels and other places, and is an indispensable core equipment in modern construction and decoration engineering.

耐久性のある構造と容易なメンテナンス

The main frame of the machine is made of thickened square pipe and H-shaped steel through welding and tempering treatment, which has high rigidity and stability, and avoids deformation during long-term high-intensity operation. The transmission part adopts high-precision gearbox drive, which is stable and reliable, with low noise (≤70dB) and long service life. The equipment is designed with humanized maintenance ports and quick-change wearing parts, and all wearing parts are standardized and easy to replace; at the same time, we provide detailed multi-language operation and maintenance manuals, and professional online guidance, which can greatly reduce the maintenance cost and downtime of customers.
