A cable tray roll forming machine is a professional full-automatic cold forming production line designed for mass manufacturing of standard and customized cable tray profiles. Also known as cable tray making machine or cable channel forming machine, it processes metal coils into finished cable trays through automatic decoiling, leveling, continuous rolling, punching, embossing, and flying cutting. It replaces traditional manual welding and bending processes, delivering uniform size, smooth surface, and higher structural strength for every finished tray.

Manufactured strictly in accordance with international electrical installation standards, our cable tray roll forming line supports production of trough-type, ladder-type, perforated, and solid-bottom cable trays. It is widely used in electrical wiring layout for industrial plants, commercial buildings, data centers, power engineering, and petrochemical projects. As a reliable China-based roll forming machine supplier, we provide standardized and fully customized cable tray production solutions for global manufacturers.

Core Advantages of Our Cable Tray Roll Forming Machine

Our upgraded automatic cable tray roll forming machine solves common industry pain points including unstable product size, low production efficiency, high labor dependence, and serious material waste. With optimized mechanical structure and intelligent control system, it brings outstanding competitive advantages for global cable tray producers:

High Forming Precision & Consistent Product Quality: Equipped with high-precision alloy steel rollers with quenching and hardening treatment, the machine ensures stable forming without deformation, scratches, or material cracking. The flying hydraulic cutting system controls length tolerance within ±1mm, and all punching holes and ventilation slots maintain uniform spacing and neat edges. All finished cable trays feature consistent flatness and verticality, fully meeting international installation standards.

Full Automatic One-stop Production: Integrated with automatic decoiler, leveling unit, servo punching system, continuous roll forming structure, hydraulic cutting and stacking platform. The entire production process requires only one worker for parameter setting and equipment monitoring. It realizes 24-hour uninterrupted continuous production, greatly reducing labor costs and improving production stability.

Strong Versatility & Flexible Customization: The equipment supports processing of galvanized steel, stainless steel, aluminum steel, and cold-rolled steel sheets. It adapts to material thickness from 0.8mm to 2.5mm, and freely adjustable tray width and side height. Users can switch between perforated trays, solid trays and ladder trays by adjusting punching programs, realizing multi-purpose production on one single line and saving workshop equipment investment.

High Production Efficiency & Low Material Loss: Adopts high-speed servo driving system, with adjustable forming speed ranging from 8m/min to 15m/min. The continuous cold roll forming process features high material utilization rate, effectively reducing raw material waste compared with traditional processing methods. High-volume continuous output significantly lowers unit production cost and improves enterprise profit margin.

Stable Operation & Low Maintenance Cost: The main frame adopts thickened steel plate integral welding structure, with strong shock resistance and long-term operational stability. Core electrical components, servo motors and hydraulic systems adopt international famous brands. The modular assembly design simplifies daily maintenance and replacement of wearing parts, reducing later operation and maintenance costs for customers.

標準技術仕様

We provide standard cable tray roll forming machines and personalized customized lines according to customers’ production requirements and local industry standards. The core parameters of the standard model are listed below for reference:

Application of Cable Tray Products

Cable trays produced by our automatic forming machine have excellent load-bearing capacity, corrosion resistance, fire resistance and weather resistance. They are ideal cable management accessories and widely used in global engineering construction fields:

Industrial Engineering: Used for cable laying and protection in factories, workshops, power plants, chemical plants, and metallurgical industries, adapting to harsh industrial environments.

Commercial & Civil Construction: Applied in office buildings, shopping malls, hotels, residential buildings, and comprehensive pipe gallery projects for standardized electrical wiring arrangement.

New Energy & Data Industry: Suitable for cable support and wiring in photovoltaic power stations, wind power projects, 5G base stations, and large data center computer room wiring systems.

Transportation Infrastructure: Widely used in subway, railway station, airport, highway tunnel and other transportation facility electrical engineering projects.

Why Choose Our Cable Tray Roll Forming Machine

As a professional export-focused roll forming machine manufacturer, we have rich experience in serving customers from Europe, Southeast Asia, the Middle East, Africa, Australia and other regions. We focus on providing high-quality equipment and one-stop customized production solutions for global cable tray manufacturers:

International Standard Quality: All equipment has passed CE certification, complying with EU safety and export standards. Every machine undergoes strict factory debugging and quality inspection before delivery to ensure stable performance and qualified quality.

Professional Customization Service: We support OEM and ODM customization. According to customers’ drawings, local standards and output requirements, we can adjust machine structure, punching modes, product specifications and production speed to meet diverse market demands.

Complete Global After-sales System: Provide overseas on-site installation guidance, operator technical training, 24-hour online after-sales support, and long-term spare parts supply. Lifetime free technical consultation ensures no worries for customer production.

Factory Direct Sales Advantage: Direct factory sales eliminate intermediate agents, providing cost-effective high-quality equipment. We support both small-batch trial orders and large-scale production line customization, helping customers reduce procurement costs and improve market competitiveness.
