The Cable Tray Roll Forming Machine is a professional automated production equipment specially designed for manufacturing various types of cable trays, which are essential supporting components widely used in global electrical engineering, construction, and infrastructure projects. As a key equipment in the electrical metal fabrication and building materials industry, it adopts advanced cold roll forming technology to process high-quality metal coils including hot-dip galvanized steel coils, cold-rolled steel coils, aluminum coils, and zinc-aluminum-magnesium coils into high-strength, dimensionally accurate cable trays with smooth surfaces and stable structural performance. This versatile machine supports the production of multiple common cable tray types, such as ladder-type cable trays, trough-type cable trays, perforated cable trays, and slot-type cable trays, making it the preferred production equipment for electrical equipment manufacturers, construction material suppliers, and engineering distributors across the globe.

Adopting continuous cold roll forming technology without high-temperature heat treatment, this machine avoids material deformation, performance attenuation and extra energy consumption caused by thermal processing, while effectively improving the surface flatness and structural rigidity of finished cable trays. The entire production line runs in a fully automatic and seamless workflow: starting from automatic coil loading, hydraulic uncoiling, precision leveling, continuous roll forming, optional synchronous punching or perforating, fixed-length cutting, to final automatic discharging and stacking of finished products. This integrated production mode ensures consistent product quality, high production efficiency and strong operational flexibility, perfectly meeting the large-scale, standardized production demands of cable trays for global electrical and construction projects.

Core Advantages of Our Cable Tray Roll Forming Machine

Multi-Type Compatibility, Wide Application Range

Our cable tray roll forming machine features an adjustable modular design, which can quickly switch production between ladder-type, trough-type, perforated and slot-type cable trays by adjusting roller positions and control parameters, without complex disassembly and replacement. It supports the production of cable trays with widths ranging from 100mm to 600mm and thicknesses from 0.8mm to 3.0mm, covering all mainstream specifications in the global market. This multi-type compatibility allows customers to meet diverse market demands with just one machine, reducing equipment investment costs and expanding product categories to seize more market opportunities.

High Production Efficiency, Large-Scale Production Capacity

Equipped with a high-performance servo drive system and optimized forming process, our machine reaches a maximum production speed of 12-25 meters per minute, which can be adjusted flexibly according to material thickness and product specifications. The fully automatic integrated production process eliminates manual operation in each link, requiring only 1-2 workers to monitor the operation, greatly improving production efficiency and reducing labor costs. Compared with traditional semi-automatic equipment, its production efficiency is increased by more than 40%, fully meeting the large-scale and urgent order demands of cable tray manufacturers for global projects.

Superior Forming Precision, Stable Product Quality

Adopting precision numerical control technology and high-precision forming rollers, the machine strictly controls the dimensional error of finished cable trays within ±0.5mm and straightness error within 2mm/m, ensuring consistent product size, stable structure and perfect fitting performance. The finished cable trays have high structural strength, strong load-bearing capacity and excellent corrosion resistance, fully complying with international quality standards including CE, ISO9001 and ASTM. Stable and reliable product quality helps customers build a good brand reputation in the international market and win the trust of global engineering customers.

Sturdy & Durable Structure, Low Maintenance Cost

The main body of the machine is made of heavy-duty steel structure, with solid welding and overall tempering treatment, ensuring no deformation during long-term high-intensity production. All key wearing parts such as forming rollers and cutting blades are made of high-strength wear-resistant materials, with a long service life. The equipment is designed for easy daily maintenance, with clear maintenance points and accessible components, reducing downtime and maintenance costs. The intelligent control system has a long-term stable operation rate, minimizing production interruptions and ensuring continuous and stable delivery.
